Aluminum and aluminum enthalpy exchangers

Flow rate 210m3/hour - Efficiency 93.6% ....Flow rate 120m3/hour - Efficiency 94.2% ....Flow rate 50m3/hour - Efficiency 95.1% ....Dimensions: 397 x 172 x 200 mm ....Weight: 2.79 kg...

Flow rate 260m3/hour - Efficiency 93% ....Flow rate 160m3/hour - Efficiency 93.7% ....Flow rate 50m3/hour - Efficiency 95.4% ....Dimensions: 455 x 230 x 200 mm ....Weight: 3.07 kg...

Flow rate 480m3/hour - Efficiency 95.1% ....Flow rate 280m3/hour - Efficiency 95.5% ....Flow rate 90m3/hour - Efficiency 96.1% ....Dimensions: 496 x 271 x 300 mmm....Weight: 4.92 kg...

Flow rate 370m3/hour - Efficiency 94.9% ....Flow rate 220m3/hour - Efficiency 95.5% ....Flow rate 80m3/hour - Efficiency 96.8% ....Dimensions: 619 x 394 x 150 mm ....Blade spacing: 2.4 mm...

Flow rate 570m3/hour - Efficiency 95.2% ....Flow rate 350m3/hour - Efficiency 95.5% ....Flow rate 105 m3/hour - Efficiency 96.2% ....Dimensions: 537 x 312 x 300 mm ....Weight: 6.12 kg...

Flow rate 210m3/hour - Efficiency 93.6% ....Flow rate 120m3/hour - Efficiency 94.2% ....Flow rate 70m3/hour - Efficiency 95% ....Dimensions: 397 x 172 x 400 mm ....Weight: 3.87 kg...

Flow rate 650m3/hour - Efficiency 95.4% ....Flow rate 390m3/hour - Efficiency 95.6% ....Flow rate 120m3/hour - Efficiency 96.4% ....Dimensions: 496 x 271 x 400 mmm....Weight: 6.26 kg...

Flow rate 750m3/hour - Efficiency 95.2% ....Flow rate 450m3/hour - Efficiency 95.5% ....Flow rate 150m3/hour - Efficiency 96.2% ....Dimensions: 537 x 312 x 400 mmm....Weight: 7.81 kg...

Flow rate 800m3/hour - Efficiency 95.4% ....Flow rate 480m3/hour - Efficiency 95.5% ....Flow rate 150m3/hour - Efficiency 96.2% ....Dimensions: 496 x 271 x 500 mmm....Weight: 7.6 kg...

Flow rate 1000m3/hour - Efficiency 95% ....Flow rate 600m3/hour - Efficiency 95.5% ....Flow rate 200m3/hour - Efficiency 95.5% ....Dimensions: 619 x 394 x 400 mmm....Weight: 9.9 kg...

Highly efficient enthalpy exchanger .... Dimensions: 397 x 172 x 200 mm ....Weight: 2.7 kg ....Material: aluminum+METALPIC .... Thermal efficiency up to 90% ....100% leak testing

Flow rate 1150 m3/hour - Efficiency 95.1% - Pressure loss 251.7 Pa ....Flow rate 700 m3/hour - Efficiency 95.4% - Pressure loss 119.6 Pa ....Flow rate 250 m3/hour - Efficiency 96.1% -...

Flow rate 850m3/hour - Efficiency 95.3% ....Flow rate 600m3/hour - Efficiency 95.4% ....Flow rate 200m3/hour - Efficiency 96.1% ....Dimensions: 1182 x 957 x 150 mm ....Blade spacing: 2.6...

Highly efficient enthalpy exchanger .... Dimensions: 455 x 230 x 200 mm ....Weight: 3.22 kg ....Material: aluminum+METALPIC .... Thermal efficiency up to 90% ....100% leak testing

Highly efficient enthalpy exchanger .... Dimensions: 619 x 150 x 394 mm ....Weight: 4.38 kg ....Material: aluminum+METALPIC .... Thermal efficiency up to 90% ....100% leak testing

Flow rate 1500m3/hour - Efficiency 95.3% ....Flow rate 900m3/hour - Efficiency 95.6% ....Flow rate 300m3/hour - Efficiency 96.2% ....Dimensions: 537 x 312 x 800 mm ....Weight: 14.57 kg...

Highly efficient enthalpy exchanger .... Dimensions: 496 x 300 x 271 mm ....Weight: 5.12 kg ....Material: aluminum+METALPIC .... Thermal efficiency up to 90% ....100% leak testing

Flow rate 1600m3/hour - Efficiency 94.8% ....Flow rate 1100m3/hour - Efficiency 95.1% ....Flow rate 330m3/hour - Efficiency 96% ....Dimensions: 899 x 674 x 400 mmm....Weight: 20.51kg...

Flow rate 2050m3/hour - Efficiency 94.5% ....Flow rate 1200m3/hour - Efficiency 94.8% ....Flow rate 370m3/hour - Efficiency 94.9% ....Dimensions: 758 x 533 x 600 mm ....Weight: 20.95 kg...

High efficiency enthalpy exchanger .... Dimensions: 537 x 300 x 312 mm ....Weight: 6.23 kg ....Material: aluminum+METALPIC .... Thermal efficiency up to 90% ....100% leak testing

Highly efficient enthalpy exchanger .... Dimensions: 496 x 400 x 271 mm ....Weight: 6.52 kg ....Material: aluminum+METALPIC .... Thermal efficiency up to 90% ....100% leak testing

Flow rate 2300m3/hour - Efficiency 96.2% ....Flow rate 1590m3/hour - Efficiency 95.3% ....Flow rate 510m3/hour - Efficiency 95% ....Dimensions: 899 x 674 x 600 mmm....Weight: 31.4kg...

Highly efficient enthalpy exchanger .... Dimensions: 537 x 400 x 312 mm ....Weight: 7.95 kg ....Material: aluminum+METALPIC .... Thermal efficiency up to 90% ....100% leak testing

Highly efficient enthalpy exchanger .... Dimensions: 496 x 500 x 271 mm ....Weight: 7.92 kg ....Material: aluminum+METALPIC .... Thermal efficiency up to 90% ....100% leak testing

High efficiency enthalpy exchanger .... Dimensions: 619 x 400 x 394 mm ....Weight: 9.33 kg ....Material: aluminum+METALPIC .... Thermal efficiency up to 90% ....100% leak testing

Flow rate 3200 m3/hour - Efficiency 95.3% - Pressure loss 299.8 Pa ....Flow rate 1700 m3/hour - Efficiency 95.4% - Pressure loss 160.6 Pa ....Flow rate 600 m3/hour - Efficiency 96.1% -...

Flow rate 3200 m3/hour - Efficiency 95.1% - 250.1 Pa ....Flow rate 2000 m3/hour - Efficiency 95.4% - Pressure loss 123.5 Pa ....Flow rate 700 m3/hour - Efficiency 96% - Pressure loss 37...

Flow rate 2500m3/hour - Efficiency 95% ....Flow rate 1100m3/hour - Efficiency 95.1% ....Flow rate 330m3/hour - Efficiency 96% ....Dimensions: 899 x 674 x 700 mmm....Weight: 36.15kg...

Flow rate 2650m3/hour - Efficiency 95.2% ....Flow rate 1900m3/hour - Efficiency 95.4% ....Flow rate 600m3/hour - Efficiency 96% ....Dimensions: 1182 x 957 x 500 mmm....Weight: 41.52 kg...

High efficiency enthalpy exchanger .... Dimensions: 537 x 800 x 312 mm ....Weight: 14.83 kg ....Material: aluminum+METALPIC .... Thermal efficiency up to 90% ....100% leak testing

Flow rate 5100 m3/hour - Efficiency 95.3% - Pressure loss 299.8 Pa ....Flow rate 3400 m3/hour - Efficiency 95.4% - Pressure loss 160.6 Pa ....Flow rate 1250 m3/hour - Efficiency 96.1% -...

Flow rate 7700 m3/hour - Efficiency 95.2% - 273.2 Pa ....Flow rate 5000 m3/hour - Efficiency 95.5% - Pressure loss 136.9 Pa ....Flow rate 1890 m3/hour - Efficiency 96% - Pressure loss 37...
