Viessmann Vitovent 300-W - RECUTECH izmjenjivač entalpije
Najučinkovitiji entalpijski izmjenjivač na tržištu s revolucionarnim materijalom rebara METALPIC – najbolji izbor za Viessmann Vitovent 300-W
Ovaj entalpijski izmjenjivač je dimenzijski identičan izmjenjivačima topline u Viessmann Vitovent 300-W jedinicama za povrat topline i uobičajeno se ugrađuje u jedinice.
Međutim, ovo nije originalni rezervni dio koji isporučuje i ugrađuje proizvođač jedinice, pa je njegova upotreba na diskreciji korisnika jedinice za povrat topline.
Serija RFK+ / RFC+ je potpuno entalpijska alternativa REK+ protustrujnim aluminijskim izmjenjivačima, koja zahvaljujući inovativnoj tehnologiji, uz toplinsku učinkovitost do 90%, nudi i vrlo visoku učinkovitost u održavanju vlažnosti. Zahvaljujući istim dimenzijama, lako je zamijeniti aluminijski i plastični izmjenjivač bez daljnjih modifikacija jedinice za povrat topline.
- Toplinska učinkovitost do 90%
- Latentna učinkovitost do 75%
- Visoka otpornost na neuravnoteženi pritisak
- Visoka selektivna propusnost
- Jedinstveni METALPIC materijal
- Najviša toplinska učinkovitost od svih entalpijskih proizvoda na tržištu
- Visoka učinkovitost vlažnosti
- Maksimalna razlika ulaznog/izlaznog tlaka od 800 Pa nadmašuje druge entalpijske proizvode s membranom na bazi polimera
- Smanjenje kondenzacije i značajno smanjenje točke smrzavanja
- Propuštanje samo vodene pare kroz visoko selektivnu propusnu membranu
- Zajamčena nepropusnost zahvaljujući 100%-tnom ispitivanju u proizvodnji
- Koristi se sa standardnim jedinicama zahvaljujući standardiziranim dimenzijama
- Eurovent certifikat, higijenski certifikat prema VDI 6022 i klasifikacija reakcije na vatru prema EN 13501-1
Visoka otpornost na neravnotežu tlaka – Zahvaljujući krutosti korištenih materijala, naši izmjenjivači mogu podnijeti neravnotežu tlaka od 800 Pa. Također omogućuju upotrebu u konfiguraciji gdje jedan ventilator u jedinici usisava zrak, a drugi ga potiskuje.
Visoka selektivnost – Naša membrana je visoko selektivna. Propušta samo vodenu paru, nikakve druge plinove. Selektivnost se provjerava testovima.
Jednostavna zamjena u postojećim instalacijama – Zahvaljujući istim dimenzijama i sličnim parametrima toplinske učinkovitosti, izmjenjivač u jedinici možete jednostavno zamijeniti entalpijskim.
Kako su postignuti ovi parametri?
To je uglavnom zbog upotrebe jedinstvenog materijala pod nazivom Metalpic, koji se koristi u Recutech izmjenjivačima entalpije. Ovaj materijal je razvijen isključivo u tu svrhu, a kreirala ga je tvrtka Recutech. To je sendvič materijal gdje svaka komponenta ima svoju jasno definiranu funkciju.
Sastoji se od posebno obrađenog ekspandiranog aluminija s najvećom mogućom otvorenom površinom. Njegova glavna funkcija je stvaranje potporne strukture za drugu komponentu, koja je vrlo tanka polimerna membrana. Zašto aluminij? Jer ovaj materijal vrlo dobro provodi toplinu i lako se reciklira.
Drugi dio sendviča je polimerna membrana. Njegova glavna funkcija je prijenos vlage i mora osigurati nepropusnost dobivenog materijala. To je membrana za ionsku izmjenu koja je selektivno propusna.
Zahvaljujući nosaču od proširenog metala, membrana može biti vrlo tanka, a što je membrana tanja, to je prijenos vlage bolji. Oba dijela ovog sendviča spojena su laminacijom.
Ovaj materijal se zatim obrađuje kao klasična aluminijska folija za izmjenjivače serije REK i REC. U ovom procesu, oba dijela ovog sendviča moraju se nositi s relativnim istezanjem tijekom istezanja poput aluminija.
Zahvaljujući tim svojstvima, moguće je stvoriti lamelu koja je ojačana tijekom oblikovanja i povećava se njezina površina za izmjenu topline i vlage. Zbog istezanja, membrana dodatno oslabljuje i kao što smo napisali Što je više, što je tanje, to je bolji prijenos vlage.
izmjenjivač zraka za rekuperaciju topline, izmjenjivač topline, pločasti izmjenjivač zraka za rekuperaciju topline
Podaci
- Proizvođač jedinice
- Viessmann
- Zemlja podrijetla
- Češka
RECUTECH are equipped with the latest enthalpic membrane METALPIC. They excel in top-class heat and humidity recovery, high resistance to pressure differences, and long service life. They are among the most advanced enthalpic heat exchangers currently available on the market.
ZERN are fully plastic enthalpic heat exchangers, very efficient, with slightly better moisture transfer, but with higher pressure loss.
No, never block the condensate drain.
Even though enthalpic heat exchangers produce only a minimal amount of condensate due to moisture transfer, in severe frost and specific humidity conditions, condensate can still occur. Blocking the drain could cause irreversible damage to your unit.
Protože entalpický výměník přenáší i vlhkost, mohlo by se zdát, že riziko vzniku plísní je vyšší. Ve skutečnosti však veškerá vlhkost odchází pryč spolu s čerstvým vzduchem, takže riziko vzniku plísní nehrozí.
Naše doporučení je v zimních měsících jednotku nikdy nevypínat, aby byl odvod vlhkosti zajištěn nepřetržitě. Pokud byste přesto potřebovali jednotku odstavit, vyjměte výměník, propláchněte jej čistou vodou, důkladně vysušte a teprve poté jej vraťte zpět.
Yes, installation is simple. Just follow the instructions provided with your unit. As with a standard exchanger, it needs to be removed occasionally for cleaning – the process is the same, except that you put the enthalpic exchanger back in instead.
I am not sure about the type of exchanger in my unit, or I did not find my unit type in your e-shop. What should I do?
Feel free to contact us with any unit model. We will do our utmost to provide you with a 100% compatible exchanger, regardless of the type of ventilation unit you have.
In some cases, the exchangers we supply are identical to the original parts used by the unit manufacturers, and in many cases, our exchangers are even of higher quality. However, we must clearly state that we are not official distributors of spare parts from the unit manufacturers. Transparency is very important to us.
An enthalpic heat exchanger should be used all year round. In winter, it prevents excessive drying of the indoor air, and in summer, it helps maintain comfortable humidity and temperature by reducing heat transfer and returning part of the moisture to the fresh supply air. This increases comfort and saves energy in every season.
No, caring for an enthalpic heat exchanger is no more demanding than for a standard one. Maintenance is described in the user manual and in our video guide. In short: first vacuum the exchanger with a soft brush attachment, then rinse it with clean water (max. 50 °C). Never use compressed air or a pressure washer.
After rinsing, allow all water to drain completely. Remaining moisture can be carefully blown out with a regular hairdryer, but always use cold air only. Once the exchanger is completely dry, place it back into the unit in the same orientation as before removal.
We do not recommend using chemicals for cleaning. Only if disinfection is absolutely necessary may a weak solution of peracetic acid be used, followed by very thorough rinsing with clean water.
Yes, the use of an enthalpic heat exchanger is completely safe. The membrane is designed to allow only water vapor molecules to pass through, while blocking bacteria, odors, and harmful substances. All enthalpic heat exchangers we offer are hygienically tested and certified.
An enthalpic heat exchanger will always help improve indoor humidity, as it transfers part of the moisture from exhaust air back into the fresh supply air. It cannot be guaranteed that ideal levels (typically 40–60%) will be achieved, since the final humidity also depends on other factors – such as household habits, number of occupants, natural moisture sources, and outdoor climate conditions.
However, we can guarantee that humidity will improve, because it is physically impossible for the return of moisture not to contribute to higher values.
The enthalpic plate works the same from both sides, so the orientation of the plate itself does not matter. However, it is essential that after cleaning the exchanger is always reinstalled in the same orientation, ensuring that the channels for fresh air remain for fresh air and the channels for exhaust air remain for exhaust air.
An enthalpic heat exchanger does not generate humidity – it maximizes the transfer of humidity from exhaust air into fresh supply air. If you previously used a standard exchanger, not only the air but also the building structure (walls, ceilings, floors) and porous materials became dry. This means it may take some time for humidity levels to recover, so patience is necessary.
Every enthalpic exchanger we supply is fully functional and improvement is guaranteed. We recommend keeping natural humidity sources (plants, cooking, drying clothes). If you use humidifiers, continue using them until the humidity rises to a comfortable level with the enthalpic exchanger, after which they can be reduced.
Yes. Unlike a standard exchanger, an enthalpic heat exchanger transfers part of the humidity back into the fresh air. This process is gradual, but you can speed it up by adding humidity – either naturally (plants, drying clothes, washing floors) or with humidifiers. Once the humidity has returned to a stable, optimal level, additional humidification can be reduced.
No, an enthalpic heat exchanger does not generate humidity by itself. It only transfers part of the moisture from the exhaust air back into the fresh supply air. If humidity in your home is too high, the cause lies elsewhere (e.g., insufficient ventilation, drying clothes indoors without venting, or residual construction moisture). The enthalpic exchanger helps balance humidity and prevents extreme fluctuations.
An enthalpic heat exchanger works on the principle of counterflow air streams. During ventilation, two separate airflows meet inside – the warm, humid exhaust air from indoors and the cold fresh air from outside. A special membrane transfers both heat and water vapor from the exhaust air to the incoming fresh air without mixing the two streams. This way, fresh air enters the home with a more comfortable temperature and humidity, improving comfort while saving energy.
The sealing tape must be applied around the perimeter of the exchanger, so that when inserted it presses firmly against the unit walls and prevents false air from being drawn in. The surface of the exchanger must be dry and clean before application. Always apply the tape straight, without gaps or folds, to ensure proper sealing.
